At t = 0 bullet A is fired vertically with an initial (muzzle) velocity of 450 m/s.When t = 3 s bullet B is fired upward with a muzzle velocity of 600 m/s. Determine the time t, after A is fired, as to when bullet B passes bullet A. At what altitude does this occur?

At bullet A is fired vertically with an initial

Image from: www.Vecteezy.com

Solution:

Show me the final answer↓

Let us write two separate kinematics equations for bullet A and bullet B. We will use the following equation:

s=s_0+v_0t+\dfrac{1}{2}at^2

(Where s is final displacement, s_0 is initial displacement, v_0 is initial velocity, t is time, and a is constant acceleration)

Remember that our acceleration is -9.81 m/s^2 since that’s the acceleration due to gravity. It’s negative because we are assuming the upward direction to be positive. Substitute the values we know:

Bullet A:

s=s_0+v_0t+\dfrac{1}{2}at^2

s=0+(450)(t)+\dfrac{1}{2}(-9.81)t^2 (eq.1)



Bullet B:

s=s_0+v_0t+\dfrac{1}{2}at^2

s=0+(600)(t-3)+\dfrac{1}{2}(-9.81)(t-3)^2 (eq.2)

(Remember that bullet B is fired 3 seconds after bullet A. Since our initial time reference is with respect to bullet A, bullet B is 3 seconds later. Also note that both bullet A and B are fired from the same height, which we will consider to be our origin, thus s_0=0 m.)



To figure out when the bullets pass each other, we must note that at that point, the height of bullet A must equal the height of bullet B. Thus, we can equal eq.1 to eq.2:

(450)(t)+\dfrac{1}{2}(-9.81)t^2=(600)(t-3)+\dfrac{1}{2}(-9.81)(t-3)^2

Solving for t yields:

t=10.28 s



The height at which the bullets are equal can be found by substituting the value of t we found to either eq.1 or eq.2. They will both yield the same answer.

s=0+(450)(t)+\dfrac{1}{2}(-9.81)t^2

s=0+(450)(10.28)+\dfrac{1}{2}(-9.81)(10.28)^2

s=4107.6 m



Final Answers:

t=10.28 s

s=4107.6 m



This question can be found in Engineering Mechanics: Dynamics (SI edition), 13th edition, chapter 12, question 12-33.
